U-manchetter / U-ringe
| Betegnelse | Materiale | Profiler | Standard Hårdhed Shore A |
Tryk - (max) bar | Temperatur °C | Glide hastighed (max. m/sek) |
Anvendelse | Mål | Pressure Rating |
Rotary Speed |
pH Range |
Dimensioner |
| CH21 U-manchet / U-ring | NBR PU FKM* |
 |
150 400 - |
-30°C+105°C -40°C+100°C -15°C+200°C* |
≤0.5 |  |
||||||
| CH22 U-manchet / U-ring | NBR PU FKM* |
 |
150 400 - |
-30°C+105°C -40°C+100°C -15°C+200°C* |
≤0.5 | |
||||||
| CH23 U-manchet / U-ring | NBR PU FKM* |
 |
150 400 - |
-30°C+105°C -40°C+100°C -15°C+200°C* |
≤0.5 | |
||||||
| CH29 U-manchet / U-ring | PU POM Støttering |
 |
400 | -30°C+100°C | ≤0.5 | |
||||||
| CH30 U-manchet / U-ring | STÅL NBR FKM* |
 |
16 | -30°C+105°C -15°C+200°C* |
≤1.0 | |
||||||
| CH31 U-manchet / U-ring | PU NBR POM Støttering |
 |
630 | -30°C+100°C | ≤0.5 | |
||||||
| CH32 U-manchet / U-ring | PU POM Støttering |
 |
400 | -30°C+100°C | ≤0.5 | |
||||||
| CH33 U-manchet / U-ring | PU |  |
400 | -30°C+100°C | ≤0.5 | |
||||||
| CH38 U-manchet / U-ring | PU |  |
400 | -30°C+110°C | ≤0.5 | |
||||||
| CH40 U-manchet / U-ring | PU POM Støttering |
 |
400 | -35°C +100°C | ≤0.5 | |
||||||
| CH44 U-manchet / U-ring | PU POM |
 |
400 | -30°C+100°C | ≤0.5 | |||||||
| CH50 U-manchet / U-ring | PU NBR FKM* |
 |
16 12 12 |
-30°C+80°C -30°C+105°C -15°C+200°C* |
≤1.0 ≤1.0 |
|
||||||
| CH51 U-manchet / U-ring | PU |  |
16 | -30°C+80°C | ≤1.0 | |
||||||
| CH52 U-manchet / U-ring | NBR PU FKM* |
 |
12 16 12 |
-30°C+105°C -30°C+80°C -15°C+200°C* |
≤1.0 | |
||||||
| CH53 U-manchet / U-ring | NBR PU FKM* |
 |
12 16 12 |
-30°C+105°C -30°C+80°C -15°C+200°C* |
≤1.0 | |
||||||
| CH54 U-manchet / U-ring | NBR FKM* |
 |
12 | -30°C+105°C -15°C+200°C* |
≤1.0 | |
||||||
| CH56 U-manchet / U-ring | NBR TPE FKM** |
 |
16 | -30°C+105°C -15°C+200°C** |
≤1.0 | |
||||||
| CH58 U-manchet / U-ring | ALUMINIUM MAGNET PU POM |
 |
16 | -30°C+80°C | ≤1.0 | |
||||||
| CH59 U-manchet / U-ring | NBR PU FKM* |
 |
12 16 - |
-30°C+105°C -30°C+100°C -15°C+200°C* |
≤1.0 | |
||||||
| CH62 U-manchet / U-ring | NBR FKM* |
 |
12 | -30°C+105°C -15°C+200°C* |
≤1.0 | |
||||||
| CH63 U-manchet / U-ring | NBR FKM* |
 |
12 | -30°C+105°C -15°C+200°C |
≤1.0 | |
||||||
| CH64 U-manchet / U-ring | PU |  |
16 | -30°C+80°C | ≤1.0 | |
||||||
| CH65 U-manchet / U-ring | NBR |  |
12 | -30°C+105°C | ≤1.0 | |||||||
| CH95 U-manchet / U-ring | NBR FKM* |
 |
150 - |
-30°C+105°C -15°C+200°C* |
≤0.5 | |
||||||
| CH96 U-manchet / U-ring | NBR FKM |
 |
150 | -30°C+105°C | ≤0.5 | |
||||||
| CH98 U-manchet / U-ring | PU NBR |
 |
400 | -30°C+100°C | ≤0.5 | |||||||
| CH114 U-manchet / U-ring | PU NBR |
 |
400 | -30°C+100°C | 0.5 | |||||||
| CH130 U-manchet / U-ring | NBR |  |
12 | -30°C +105°C | ≤1.0 | |||||||
| CH701 U-manchet / U-ring | PTFE U-Manchet V-FJEDER |
 |
350 | -150°C+250°C | ≤15.0 | |
||||||
| CH715 U-manchet / U-ring | PTFE NBR |
 |
40 | -30°C+105°C | ≤10.0 | |||||||
| CH751 U-manchet / U-ring | PTFE U-Manchet V-FJEDER |
 |
350 | -150°C+250°C | ≤15.0 | |
||||||
| CH761 U-manchet / U-ring | PTFE NBR |
 |
40 | -30°C+105°C | ≤10.0 | |||||||
| CH762 U-manchet / U-ring | NBR PTFE |
 |
400 | -30°C +105°C | ≤0.5 | |||||||
| CHFR U-manchet / U-ring | PU |  |
400 | -35°C+110°C | 0.5 | |||||||
| CHXT U-manchet / U-ring | PU |  |
400 | -35°C+110°C | 0.5 | |||||||
| UI GE U-manchet / U-ring | NBR Gummilærred POM |
 |
400 | - | 0,5 | |||||||
| UA GE U-manchet / U-ring | NBR GUMMILÆRRED POM |
 |
400 | - | ≤0.5 |
